Product Description

Triac Dimming 25W AC 110V to DC 24V LED Power Supply Mini Lighting Transformer

Dimension for Triac LED Power Supply

25W: 155*54*20mm

Triac Dimming 25W AC 110V to DC 24V LED Power Supply Mini Lighting Transformer

Voltage Accuracy: ±0.5V
Voltage Range: 90-130VAC, 180~250VAC
Frequency Range: 47~63HZ
Full load Efficiency (Typ.): 88%
Leakage Current: <0.70mA/220VAC
Short Circuit: Intermittent Restart Mode, Automatically Recover after Exception Eliminated
Overload: <=120%
Working Temperature: -40~+60ºC
Working Humidity: 20~90%RH, non-condensing
Storage Temperature and Humidity: -40~+80ºC, 10~95%RH
Temperature Coefficient: ±0.03%/ºC (0~50ºC)
Vibration Resistance: 10~500Hz, 2G 10 minutes/cycle, X, Y, Z axis each for 60 minutes
Safety Regulations: EN61347-1 EN61347-2-13
Withstand Voltage: I/P-O/P: 3.75KVAC
Insulation Resistance: I/P-O/P: 100MΩ/500VDC/25ºC/70%RH
Electromagnetic Compatibility Emission: EN55015, EN61000-3-2, 3 (>=50% load)
Electromagnetic Compatibility Immunity: EN61000-4-2,3,4,5,6,11 (surge 4KV)

Triac Dimming 25W AC 110V to DC 24V LED Power Supply Mini Lighting Transformer

Triac Dimmable Led Driver

Air / DHL / FedEx / PostNL / Custom-Free Shipping

Warranty policy:
1: Warranty: 3 years.
2: 100% of all products will be tested before shipping by our QC staff.
3: During the warranty period, we will immediately supply replacement for free.
4: Promot technciail supports and led solution will be offered!
5: Favorable price according to large qty.
6: Once partnership established, newest and hottest products information
