Home > Products > LED Power Supply > LED Driver Adapter 50W AC DC 220V to 24V Triac Dimmable Power Transformer
LED Driver Adapter 50W AC DC 220V to 24V Triac Dimmable Power Transformer
LED Driver Adapter 50W AC DC 220V to 24V Triac Dimmable Power Transformer 50W: 178*61*24mmVoltage Accuracy: ±0.5VVoltage Range: 90-130VAC, 180~250VACFrequency Range: 47~63HZFull load Efficiency (Typ.): 88%Leakage Current: <0.70mA/220VACShort Circuit: Intermittent Restart Mode, Automat......
Send Inquiry
Product Description
LED Driver Adapter 50W AC DC 220V to 24V Triac Dimmable Power Transformer
50W: 178*61*24mm
Voltage Accuracy: ±0.5V
Voltage Range: 90-130VAC, 180~250VAC
Frequency Range: 47~63HZ
Full load Efficiency (Typ.): 88%
Leakage Current: <0.70mA/220VAC
Short Circuit: Intermittent Restart Mode, Automatically Recover after Exception Eliminated
Overload: <=120%
Working Temperature: -40~+60ºC
Working Humidity: 20~90%RH, non-condensing
Storage Temperature and Humidity: -40~+80ºC, 10~95%RH
Temperature Coefficient: ±0.03%/ºC (0~50ºC)
Vibration Resistance: 10~500Hz, 2G 10 minutes/cycle, X, Y, Z axis each for 60 minutes
Safety Regulations: EN61347-1 EN61347-2-13
Withstand Voltage: I/P-O/P: 3.75KVAC
Insulation Resistance: I/P-O/P: 100MΩ/500VDC/25ºC/70%RH
Electromagnetic Compatibility Emission: EN55015, EN61000-3-2, 3 (>=50% load)
Electromagnetic Compatibility Immunity: EN61000-4-2,3,4,5,6,11 (surge 4KV)
Triac Dimmable Led Driver
Dimension for Triac LED Power Supply
Air / DHL / FedEx / PostNL / Custom-Free Shipping
Warranty policy:
1: Warranty: 3 years.
2: 100% of all products will be tested before shipping by our QC staff.
3: During the warranty period, we will immediately supply replacement for free.
4: Promot technciail supports and led solution will be offered!
5: Favorable price according to large qty.
6: Once partnership established, newest and hottest products information
50W: 178*61*24mm
Voltage Accuracy: ±0.5V
Voltage Range: 90-130VAC, 180~250VAC
Frequency Range: 47~63HZ
Full load Efficiency (Typ.): 88%
Leakage Current: <0.70mA/220VAC
Short Circuit: Intermittent Restart Mode, Automatically Recover after Exception Eliminated
Overload: <=120%
Working Temperature: -40~+60ºC
Working Humidity: 20~90%RH, non-condensing
Storage Temperature and Humidity: -40~+80ºC, 10~95%RH
Temperature Coefficient: ±0.03%/ºC (0~50ºC)
Vibration Resistance: 10~500Hz, 2G 10 minutes/cycle, X, Y, Z axis each for 60 minutes
Safety Regulations: EN61347-1 EN61347-2-13
Withstand Voltage: I/P-O/P: 3.75KVAC
Insulation Resistance: I/P-O/P: 100MΩ/500VDC/25ºC/70%RH
Electromagnetic Compatibility Emission: EN55015, EN61000-3-2, 3 (>=50% load)
Electromagnetic Compatibility Immunity: EN61000-4-2,3,4,5,6,11 (surge 4KV)
Triac Dimmable Led Driver
Dimension for Triac LED Power Supply
Air / DHL / FedEx / PostNL / Custom-Free Shipping
Warranty policy:
1: Warranty: 3 years.
2: 100% of all products will be tested before shipping by our QC staff.
3: During the warranty period, we will immediately supply replacement for free.
4: Promot technciail supports and led solution will be offered!
5: Favorable price according to large qty.
6: Once partnership established, newest and hottest products information
