              24V 100W High Power IP67 Waterproof LED Strip Power Supply
              • 24V 100W High Power IP67 Waterproof LED Strip Power Supply24V 100W High Power IP67 Waterproof LED Strip Power Supply

              24V 100W High Power IP67 Waterproof LED Strip Power Supply

              Product Description:1. Design with PWM Switch Technical: High Performance, Stable, Low energy wastage, High effect,About 50% Lower energy wastage compare to normal transformer.2. Power protection: Overload, OverVoltage, Overcurrent, Shortcircuit protect.3. Widen Input voltage range: (Volage: 170-250......

              Send Inquiry

              Product Description

              24V 100W High Power IP67 Waterproof LED Strip Power SupplyProduct Description:24V 100W High Power IP67 Waterproof LED Strip Power Supply
              24V 100W High Power IP67 Waterproof LED Strip Power Supply1. Design with PWM Switch Technical: High Performance, Stable, Low energy wastage, High effect,
              About 50% Lower energy wastage compare to normal transformer.
              2. Power protection: Overload, OverVoltage, Overcurrent, Shortcircuit protect.
              3. Widen Input voltage range: (Volage: 170-250V AC90-250V).
              4. Cover with Aluminum-Co-metal material, high performance for reduce heat, temperature raise less than 28C
              6. ProtectIon Rank. IP67.
              Installation:
              1. Power supply should be installed for heat reduce easy, air flow, not allowed to approach heater.
              2. Avoid work in abnormal condition for long term, such as voerload, shortcircuit, overvoltage Etc.
              3. Working voltage and current should according to specification.
              4. Wire connection should be stable and insulation to aviod leakage shot.
              MODEL:JA-24100Q  INPUT VOLTAGE RANGE:AC170-250V 50/60Hz
              OUTPUT VOLTAGE:DC24±0.5V
              RATED OUTPUTELECTRICITY:DC4.16A
              OUTPUT POWER:DC100Wmax
              DIMENSION(mm)
              WEIGHT:1300G/PCS
              MEASUREMENT:50PCS/13KG(340X240X190MM)
              Colour:silver
              Certried:CE/ROHS/(CONSTANT VOLTAGE)
              REQUIRMENT:SVT/VDEINPUT& OUTPUT WIRE,LENGTH:200MM (2-WAYS OUTPUT)
