Product Description

24V 1.25A 30W 100-130VAC Constant Voltage Triac Phase Cut Dimming LED Driver

Feature

·Output constant voltage

·Universal AC input: 100-130VAC

·High efficiency :up to 86%

·Protection:short circuit/over loading/over current/ Over temperature

·Full protection plastic housing

·Easy installation

·Cooling by free air convection

·Compatible with Forward & Reverse phase, Triac, ELV Dimmers

·Strong compatibility, flicker-free dimming

·Suitable for LED lighting and moving sign applications and others

·Suitable for dry or damp location use, IP20

Specification

Model		KV-12030-TDL	KV-24030-TDL	KV-36030-TDL	KV-48030-TDL
Certificates		ETL,cETL,FCC	ETL,cET,FCC	ETL,cETL,FCC	ETL,FCC
Output	DC Voltage	12V	24V	36V	48V
	Voltage Tolerance	±0.5V
	Rated current	2.5A	1.25A	0.83A	0.62A
	Rated power	30W
Input	Voltage Range	100~130VAC
	Frequency Range	47~63HZ
	Power Factor	PF≥ 0.95 (Full loading)
	Efficiency(Typ.)	81%	83%	85%	86%
	AC Current(Max.)	0.41A	0.4A	0.39A	0.38A
	Leakage current	<0.50mA/120VAC
Protection	Short Circuit	Hiccup mode, recover automatically after fault condition is removed
	Over Current	≤1.2*I out
	Over Loading	≤120%
	Over temperature	100ºC±10ºC,Shut down o/p voltage,recover automatically after temperature goes down.
Others	Net. Weight	0.55Kg
	Size	1806035mm(LWH)
	packing	350195180mm 20PCS/CTN
Notes	1. All parameters if NOT specially mentioned are measured at 120VAC input , rated load and 25ºC of ambient temperature. 2. To extend the driver's using life ,please reduce the loading at lower input voltage. 3.Loading should be 60-100%.
