Relay Control 8000va Automatic Voltage Stabilizer
1. PC-TLR series Relay control voltage stabilizer has the low energy consumption,the over voltage protection,the low voltage protection,the over-current protection,the over-loading protection,the over-temperature protection and so on.It boasts for many kinds of protections,the collection energy con......
Send Inquiry
Product Description
1. PC-TLR series Relay control voltage stabilizer has the low energy consumption,the over voltage protection,the low voltage protection,the over-current protection,the over-loading protection,the over-temperature protection and so on.It boasts for many kinds of protections,the collection energy conservation and the environmental protection ect.This is a brand-new concept product which possess many new technologies!This series products simultaneously ha applied for many technical monopolies
2. Use for equipment:
Computer
Test equipment
Light system
Safe alarm system
Ray equipment
Medical equipment
Copy machine
Stereo equipment
Numerical control machine tools
Industrial automation equipment
Color and drying equipment
Test equipment
Hi-Fi equipment
3. PERFORMANCE
4. The Features of PC-TLR
1.High technology:programmed control computerized
2.Unique design:LED display which can show all protection functions.
3.Quality ensurance:every spareparts is made by ourself,for example,transforma,PCB.
4.Perfect protection function:over/low voltage protection,over-heat,over-load protection
5.High efficiency:more than 90%FAQ
5.COMPANY INFORMATION:
1.We are professional manufacturer of Voltage Stabilizer/Car power inverter/UPS/Solar control system founded in 1994 year with 33,000 square meter building.
2. We have best Research/Development Department,one of our technician have more than 20years experience produce voltage stabilizer .
3.We have strictly Test systems and equipment of PCBA/transformer/finished product,check each step,each article goes through a strategic pass,lets the users be satisfied.
4.As manufacturer we have 12 product lines, daily output 2500pcs. We can expedite for you every day, guarantee not delay your delivery time.
5. Best OEM/ODM service.
6.OUR SERVICES
1. Service for sample:
We can provide sample for your testing
2. Service for Customization:
We can do as your requirement, we accept OEM.
3. After-sale service
Policy:1.sent the spareparts, 1 years warranty.
2.sent you the documents of technical skills for repairing the cargo
The sparepartsfor example will be sent,LED display,PCB,carbon brush in case of demage, which will be sent together with the cargos.
7.Certificate
2. Use for equipment:
Computer
Test equipment
Light system
Safe alarm system
Ray equipment
Medical equipment
Copy machine
Stereo equipment
Numerical control machine tools
Industrial automation equipment
Color and drying equipment
Test equipment
Hi-Fi equipment
3. PERFORMANCE
| MODEL | PC-TLR3000VA | PC-TLR5000VA | PC-TLR8000VA | PC-TLR10000VA | PC-TLR12000VA | |
| TECHNOLOGY | RELAY CONTROL SYSTERM+MICRO COMPUTER PROGRAMED CONTROL | |||||
LED DISPLAY | INFORMATION | INPUT VOLTAGE/OUTPUT VOLTAGE/LOAD USAGE/TIME DELAY/NORMAL WORKING/PROTECTION | ||||
PROTECTION | Over Voltage | Output Voltage≥243±4v | ||||
| Low Voltage | Output Voltage≤188v±4v | |||||
| Over Loading | More Than 120% | |||||
| Over Temperture | 120ºC±10ºC | |||||
| Delay Time | Long time(255 seconds)/Short time(5 seconds) | |||||
| Creepage | ||||||
| Language | English/Russia/Chinese | |||||
| Input Voltage | AC150-270V(A TYPE);AC135-AC270V(B TYPE) AC105-AC270(C TYPE);AC80V-AC270V(DTYPE) | |||||
| Output Voltage | 220+/-10% adjustable | |||||
| Frequency | 50Hz/60Hz | |||||
| Phase | Single phase | |||||
| Efficency | ≥90% | |||||
| Ambient Temperature | -15ºC-45ºC | |||||
| Relative humidity | <95% | |||||
| Waveform distortion | No additional wave from distortion | |||||
| Insulation resistance | Normally more than 2MΩ | |||||
| Power | 3000VA | 5000VA | 8000VA | 10000VA | 12000VA | |
| Packing size(cm) | 43.2*31.9*39.9 | 45.7*34.9*43.9 | 45.7*34.9*43.9 | 51.8*39.0*27.0 | 51.8*39.0*27.0 | |
| Packing (pcs) | 2 | 2 | 2 | 1 | 1 | |
1.High technology:programmed control computerized
2.Unique design:LED display which can show all protection functions.
3.Quality ensurance:every spareparts is made by ourself,for example,transforma,PCB.
4.Perfect protection function:over/low voltage protection,over-heat,over-load protection
5.High efficiency:more than 90%FAQ
5.COMPANY INFORMATION:
1.We are professional manufacturer of Voltage Stabilizer/Car power inverter/UPS/Solar control system founded in 1994 year with 33,000 square meter building.
2. We have best Research/Development Department,one of our technician have more than 20years experience produce voltage stabilizer .
3.We have strictly Test systems and equipment of PCBA/transformer/finished product,check each step,each article goes through a strategic pass,lets the users be satisfied.
4.As manufacturer we have 12 product lines, daily output 2500pcs. We can expedite for you every day, guarantee not delay your delivery time.
5. Best OEM/ODM service.
6.OUR SERVICES
1. Service for sample:
We can provide sample for your testing
2. Service for Customization:
We can do as your requirement, we accept OEM.
3. After-sale service
Policy:1.sent the spareparts, 1 years warranty.
2.sent you the documents of technical skills for repairing the cargo
The sparepartsfor example will be sent,LED display,PCB,carbon brush in case of demage, which will be sent together with the cargos.
7.Certificate
