Wholesale 12V DC LED Strip Power Adapter
Features:Universal Input: 100-240V AC 50/60HzSafety: TUV/GS/CE/CCC complianceRoHS ComplianceHigh efficiency & low power consumptionShort Circuit ProtectionOver Current ProtectionOver Voltage ProtectionLight Weight & CompactEnvironmental:Operating Temperature: 0 ~ +40 degrees centigradeStorag......
Send Inquiry
Product Description
Features:
Universal Input: 100-240V AC 50/60Hz
Safety: TUV/GS/CE/CCC compliance
RoHS Compliance
High efficiency & low power consumption
Short Circuit Protection
Over Current Protection
Over Voltage Protection
Light Weight & Compact
Environmental:
Operating Temperature: 0 ~ +40 degrees centigrade
Storage Temperature: -40 ~+70 degrees centigrade
Operating Humidity: 10% ~ 90% RH Non-condensing
Storage Humidity: 5% ~ 95% RH Non-condensing
Mechanical:
Dimensions: 65mm (L)*27mm (W)*39mm (H)
N. W.: 70g
AC Input Plug: European 2 round pin
Output plug: Optional
Packing details:
1 piece per plastic bag + inner box
100PCS/CTN
G. W.: 8.0KGS/CTN
N. W.: 6.7KGS/CTN
CTN Dimension: 50(L)*24(W)*34(H)CM
Universal Input: 100-240V AC 50/60Hz
Safety: TUV/GS/CE/CCC compliance
RoHS Compliance
High efficiency & low power consumption
Short Circuit Protection
Over Current Protection
Over Voltage Protection
Light Weight & Compact
Environmental:
Operating Temperature: 0 ~ +40 degrees centigrade
Storage Temperature: -40 ~+70 degrees centigrade
Operating Humidity: 10% ~ 90% RH Non-condensing
Storage Humidity: 5% ~ 95% RH Non-condensing
Mechanical:
Dimensions: 65mm (L)*27mm (W)*39mm (H)
N. W.: 70g
AC Input Plug: European 2 round pin
Output plug: Optional
Packing details:
1 piece per plastic bag + inner box
100PCS/CTN
G. W.: 8.0KGS/CTN
N. W.: 6.7KGS/CTN
CTN Dimension: 50(L)*24(W)*34(H)CM
| Model | Output Load Voltage (V) | Max. Load Current (A) |
| YS12E-XX240 | 24 | 0.50 |
| YS12E-XX150 | 15 | 0.80 |
| YS12E-XX120 | 12 | 1.00 |
| YS12E-XX090 | 9 | 1.20 |
| YS12E-XX075 | 7.5 | 1.50 |
| YS12E-XX060 | 6 | 1.50 |
| YS12E-XX050 | 5 | 1.50 |
