Switching Power Adapters 48V 500mA AC DC Power Adapters with CE UL FCC Certificate

car DVD player ac adapter 10v 1.3a adapter

Key Specifications/Special Features:

*10W series external wall-mount AC/DC switching power adapter (AC/DC adapter), class II, LPS, Universal input.
*Customized designs are available
*Model number: MKS-10001300
*Reliability:
     100% full loading, 40°C, 4 hours each part of this series can be sold separately
     MTBF: meet MIL-HDBK-217F over 50,000 hours, full loading, 25°C burn-in
     Leakage current: 0.25mA, maximum at 264V AC
     Withstanding voltage: 3kV, 1 minute, 10mA (maximum), between primary and secondary
*Protection:
    Over-voltage protection
    Over-current Protection
    Short-circuit protection
    Thermal shutdown capability
*Humidity:
    Operating: 10 to 95% RH
    Storage: 10 to 95% RH
*Temperature:
    Storage: -20 to 65°C
    Operating: 0 to 40°C
*Emission and immunity:
    EN 55024/A1:2001
    CISPR 22 class B
    FCC part 15 class B
    CNS 13438 class B
    EN 55022 class B
    AS/NZS 3548 and AS/NZS 4251.1 class B
    IEC61000-4-2/3/4/5/6/11
    GB 9254-1998/GB 17625.1-2003
*Features:
    LED light indicator
    High Quality Competitive Price
    High-reliability
    High-efficiency consumption
    Light and portable ,convenient to carry , easy to use
    With fuse, short-circuit protection
    Environmently friendly, energy-saving, complying with the safe certification standard
    Double insulated circuit board designed to protect your valuable gadgets from short circuit
*Certifications:
    AS/NZS 60950:2000 and AS/NZS 60065
    UL 60950 and GB 4943-2001
    PSE IEC 60950 and EN60065
    CE (low-voltage directive)
    EN 60950:2009 and EN 60065
    Standards: US Energy Star, CEC, AS, MEPS, EUP and ErP
*Input Specifications:
    Inpout Voltage: 100 to 240V AC
    Input frequency range: 50 and 60Hz
    No loading power: 0.3W (240V AC)
    Current:300mA (maximum)
    Inrush current (240V AC): 25A, cold 25°C
    Efficiency: Conform to Level V (CEC/ERP/MEPS)
    Plug type: wall mount
*Output Specifications:
    Output power: 18W Max
    DC voltage: 5-30V DC,
    Output current: 0.1-3A
    Regulation: Line: ±1%, Load: ±5%
    Ripple and noise:100mV max
    Voltage precision: 5%
    DC cord: According to the customer' s requirements
    Normal wire length: 1.5m ,1.8m , 2.0m and so on
    DC Plug Specification:5.5*2.5,5.5*2.1,3.5*1.35and so on
*application :
    LED display, led strip, nixie tube, street light, lamp
    Electrical equipment, Instrumentation
    Digital and electronic products
    LCD, LED, CCTV camera
    Building lighting decoration
    Communications and security products

Packaging & Shipping
PE bag+white Box+Carton
Caton size:375*315*295mm
1PCS/Box, 96PCS/Carton

  Shipping  Details:

  1.  By air
   Your order will be delivered by DHL, FEDEX, UPS, TNT, or other International Express. It's up to you to    choose your suitable express company. It normally takes 3-7 days to arrive at your destination. Surcharge will   be charged if your destination is remote area.
   2.  By sea
   Shipments will be operated under FOB conditions.


Our Services

1.We will send samples to your confirmation.
2.We welcome customers to check mass goods before delivery
3.You can ask refund goods in 30 days after you get goods,and all of the cost we will afford if the reason is ours,What's more we will give you the new products as soon as possible

MERRYKING advantage:
Aging test
Aging test, many manufactures test for only one hour so that it can save time. But for our company, we will test four hours in order to make sure the quality of the product and protect the user's safety.
High quality materials

To be honest, we will provide the high quality materials with reasonable prices. We believe that MERRYKING will be assured good power supply in the same industry.
Best quality service

Three is a professional sales team and technical team in our company. Our staffs can provide the best service for you and answer your products' questions in the particular time.

FAQ
1 :What are the main products in your company?
Our main products include switching power supply, power adapters, lithium battery chargers .
2 :What are your products have been certified?
our products have assed UL,CUL,FCC,CCC,GS,CB,CE,TUV,SAA,KC,ROHS and PSE certification. In other to make the customers understand our products qualities clearly. We will provide the related certifications as the customer requirements.
3:Can you give me more details about the price of your products?
We think our prices are very reasonable. If you purchase the quantity of product more enough, we will give you discount.
4: Would you please kindly tell us the below details for suggesting you the suitable adapter?
   1) What's the input please? eg:100-240VAC, 50/60Hz
   2)What's the output, please? eg: 5V DC 2A
5:How to choose suitable power adapter ?
   1) If your product working current is 1A ,we suggest you to use 12v 1.5A model ,so the adapter can keep good working status and long life ,and the working temperature is very low ,the 12v 1.5A adapter's price is nearby with 12v 1A .
    2) If your product is belong to medical device ,the quality standard should be IEC 60601 ,if your product is belong to IT device ,the quality should be IEC 60950
6. Payment
  You can pay for the order via :T/T,L/C,D/P,Western Union.

Safety Certification Standards:
 ISO9001:2008 system is fully implemented in our management. Our products have passed most of safety approvals in the world, including UL, cUL, FCC, PSE, GS, CE, SAA, CCC, C-tick, CB, etc.
